Digi DC-788 Counting Scales & Weighing Systems

DIGI DC Scales have earned a reputation for delivering quality and innovation to industrial businesses through the United States. This unique line of counting equipment is designed to provide solutions for a wide range of applications, from basic portable scales for straight weighing to high-powered counting systems.

DIGI DC-788 Series Counting Scale

The DIGI DC-788 exceeds all expectations of a counting scale — at a price point that can’t be beat! With a capacity of up to 100 pounds, and an optional rechargeable battery that provides up to 24 hours of continuous usage, this durable counting scale offers tremendous power and virtually unlimited flexibility. Its bright red LCD display can be seen from any angle and is highly visible in low light areas.

The DC-788 is an affordable counting scale that offers practical solutions for a full range of counting applications. Its counting resolution of 1/1,000,000 gives you maximum counting precision and accuracy. Its high-visibility red LCD display enables operators to easily see weights and quantities. With the ability to store an item code, part number, part name, lot number, tare weight, unit weight, inventory quantity and setpoint value for 100 of your pieces, parts, or items, the DC-788 is a self-contained inventory system. The RS-232 output allows you to connect to a printer or PC, while the remote scale channel lets you add another weighing platform. When portability is required, choose the battery operation option of the DC-788 for over 24 hours of continuous use in mobile workstations, outdoor applications, and rental fleets. Its splash-proof housing make the DC-788 rugged enough to operate reliably in many environments and withstand transport from one area of the plant to another or from one business to the next. If accuracy and ease-of-use are important, the DC-788 is a must-have. With its RS-232 interface, you can easily attach a scanner or printer for all your labeling applications. And only the DC-788 enables you to customize your output by allowing specific spec codes to be disabled. With the DC-788’s increased capacity and power, you can now do much more economically!

DC-788 Counting Scale Brochure

PART # ..... MODEL ..... CAPACITY ..... RESOLUTION .... PLATTER .............. SHIP WT

88928 ..........DC-788 ......2.0 lb ...........0.0002 lb .................7" x 10" ...........15 lb (7 kg)

88929 ..........DC-788 ......10 lb ...........0.001 lb ......................9" x 12" ..........15 lb (7 kg)

88930 ..........DC-788 ......20 lb ............0.002 lb ......................9" x 12" ..........15 lb (7 kg)

88931 ..........DC-788 ......50 lb ............0.005 lb ...................9" x 12" ..........15 lb (7 kg)

88932 ..........DC-788 ......100 lb ...........0.01 lb .....................9" x 12" ..........15 lb (7 kg)

Options Available

88933 ..........Rechargeable battery–lead acid type
73386 ..........Anti-static sample tray
32375 ..........14-pin load cell connector, Amphenol
91685 ..........Additional operating and service manual
37528 ..........9-pin cable to Zebra LT/TLP series
72440 ..........9-pin cable to Epson TM-U220/TM-U295
66535 ..........9-pin cable to PC, null modem cable
Various ........ Remote Bench or Floor Scale
Various ........ Printer

For more information or to place an order, call (919) 776-7737
